Insulated Booster VICTRON Orion-Tr Smart 12/12
VICTRON Orion-Tr Smart 12/12 Insulated Booster - 18Ah
Input voltage: 8 - 17V
Output rated voltage: 12.2V
Adjustable output voltage: 10 - 15 V
Input voltage shutdown: 7 V / Restart 7.5 V
Output voltage tolerance: +/- 0.2V
Constant output current at 40°C: 18 A
Maximum output current (10 seconds) at nominal voltage: 25 A
Short circuit output current: 40 A
Maximum cable section: 16 mm²
VICTRON Orion-Tr Smart 12/12 Insulated Booster - 30Ah
Input voltage: 8 - 17V
Output rated voltage: 12.2V
Adjustable output voltage: 10 - 15 V
Input voltage shutdown: 7 V / Restart 7.5 V
Constant output current at 40°C: 30 A
Maximum output current (10 seconds) at nominal voltage: 40 A
Short circuit output current: 60 A
Screw terminal block Maximum cable section: 16 mm²
Compatible : Acid / GEL / AGM / Lithium
Please select the desired model in the drop-down menu.
